C- Inverter/Charger/Solar 5kW 48V 100A solar charger

Tracer

$1,900.00

or 6 weekly payments from $316.67 Group Created with Sketch. learn more

Quantity

EPEVER UP5000-M10342 48v 4000w inverter charger

The UPower series is a new type of the inverter/charger combining with solar & utility charging and AC output, which adopts a multi-core processor design and advanced MPPT control algorithm, and has the features of high response speed, high reliability and high industrialization standard. It offers four charging modes to including Solar priority, Utility priority, Solar and Utility & Solar; two output modes for Battery and Utility, meeting the various application demands. The up-to-date optimized MPPT tracking technology is adopted for the PV charging modules.

Product Features:

Adoption of the advanced SPWM technology, with pure sine wave output
Fully digitalized voltage and current double closed-loop control
Advanced MPPT technology, with efficiency no less than 5%
Four charging modes: Solar priority, Utility priority Utility Solar and Solar only
Two OUTPUT mode: Battery and Utility
LCD design that enables dynamic display of system running data and operating state
Provided with common interface and advanced interface
Multiple LED indicators that instantly indicate the operating state of the system
2P circuit breaker provided at the utility input end
Independent control of AC output by AC OUT button
Battery temperature compensation function
Nominal battery voltage = 48VDC

Battery input range = 43.2 ~ 64VDC

Inverter Output:

Continuous output power = 4000W

Output power (15min) = 5000W

Overload Power (5s) = 8000W

Max. surge power = 10000W

Output voltage range = 230VAC (-10% ~ +3%)

Output frequency = 50+/-0.1 Hz

Output mode = Single phase

Output wave = Pure Sine Wave

Max efficiency = 95%

Transfer time = 0 ~ 20ms

Utility Input:

Utility input voltage range = 160VAC ~ 280VAC (working voltage range) / 170VAC ~ 270VAC (Untility starting voltage range)

Max. Utility charge current = 30A

Solar Charging:

Max. PV open circuit voltage = 200V

Max. PV input power = 5000W

Max. PV charging current = 100A

Equalization voltage = 58.4V

Boost Voltage = 57.6V

Float Voltage = 55.2V

Tracking efficiency = <99.5%

Max. charging conversion efficiency = 98%

General:

Zero load consumption = <0.8A

Enclosure = IP30

Relative humidity = <95% (N.C.)

Working environment temperature = -20C ~ 50C (full input and output with no derating)

Mechanical Parameters:

Dimensions = 614mm x 315mm x 178mm

Mounting dimension = 230mm

Mounting hole size = 8mm

Net weight = 17.8kg

SKU: UP5000 TAG: Inverter/chargers
